Ultra-high performance concrete prefabricated part pouring mold
(10) CN119773035
(22) 13.03.2025
(43) 08.04.2025
(57) The invention relates to the technical field of building material production equipment, and one embodiment of the invention provides an ultra-high performance concrete prefabricated part pouring mold which comprises a first side plate; the second side plates and the first side plates are arranged in an included angle mode, the second side plates are arranged on the first side plates in a sliding mode, the first side plates and the second side plates are symmetrically arranged in pairs, and a forming space is formed between the two first side plates and the two second side plates; the forming bottom plate is arranged in the forming space in a lifting and sliding manner; and the first pushing and pressing piece is arranged on the second side plate in a lifting and sliding mode, the first pushing and pressing piece is arranged in a horizontal moving mode relative to the forming bottom plate, and the first pushing and pressing piece is configured to provide extrusion force of the second side plate towards the forming space after horizontal movement. By means of the technical scheme, the technical problem that a penetrating type connecting piece used by a forming mold of a concrete prefabricated ...
(71) China Railway Jian’an Engineering Design Institute Co., Ltd., China Railway 20 Bureau Group Corporation, Jingnan (Gu’an) Urban Development and Construction Co., Ltd., CN
