Energy-saving concrete prefabricated part distributing device for roadbed protection and drainage engineering and forming method of ...

(10) CN121316098

(22) 25.09.2025; (43) 13.01.2026

(57) The invention relates to the field of energy-saving building material production, in particular to an energy-saving concrete prefabricated part distributing device for roadbed protection and drainage engineering and a forming method of the energy-saving concrete prefabricated part distributing device. The energy-saving concrete prefabricated part distributing device comprises a frame body and a transverse frame capable of moving in the length direction of the frame body, and further comprises a vertical arm arranged on the transverse frame in a sliding mode, the shaft piece is rotationally connected with two assembly plates, vibrating rods are arranged on the two sides of each assembly plate, the two assembly plates form a V-shaped material stirring plate set moving in the length direction of the frame body, concrete in the middle of the mold is stirred and filled into deep grooves in the two sides of the mold, and the problem that flowing of the concrete is limited is solved in cooperation with use of the vibrating rods. By means of the material distribution mode, the concrete can be vibrated while the vibration rod distributes the materials, the concrete does not need to enter the deep groove of the mold for operation after material distribution is finished, and therefore impact damage to the mold is avoided, and guarantee is provided for the engineering quality of energy-saving building materials.

(71) CCCC First Highway Fifth Engineering Co., Ltd.; CCCC First Highway Engineering Group Co., Ltd., CN
