Adjustable Concrete Forms
(10) US2025361685A1
(22) 07.08.2025
(43) 27.11.2025
(57) Adjustable concrete forms including a landing form and a ramp form. The landing form includes jacks and landing brace members. The jacks are height adjustable. The landing brace members are supported by the jacks at a selected height. The landing brace members define a landing formwork configured to contain poured concrete in a desired landing shape. The ramp form defines a ramp formwork and is pivotally coupled to the landing form. The ramp form includes ramp brace members and couplers. The ramp brace members pivotally couple to the landing brace members and extend from the landing brace members towards a ramp start boundary. The couplers couple to the ramp brace members proximate the ramp start boundary and selectively couple to a structure proximate the ramp start boundary. The slope of the landing formwork and the slope of the ramp formwork are adjustable by selectively adjusting the height of the jacks.
(71) Acuff Michael, Salem, OR, US
