FILIGRAN TRÄGERSYSTEME

Tried and tested for decades

Figure: Filigran

FDB FILIGRAN^® punching shear reinforcement – with projecting loops for maximum loading with more than 100 % load increase for extraordinary reliability in design and execution, and for optimization potential at the component

Figure: Filigran

The FILIGRAN® construction system has become firmly anchored in building construction – in particular, FILIGRAN^® floor slabs as synonyms for a remarkable cost-efficient reinforced-concrete construction method with proven advantages.

The company FILIGRAN^® Trägersysteme GmbH & Co. KG has decisively contributed to the development of this construction method. It has lent its name for nearly 70 years to support the higher-ranking interests of this industry in the most diverse ways – in work in pattern-setting bodies, associations and committees.

The company develops, manufactures and markets a range...
